HSCR01 COCOA ROASTER

HARTANZAH 1KG COCOA ROASTER

HSCR01 COCOA ROASTER

BRING OUT THE BEST FLAVOUR FROM YOUR COCOA BEAN

State of the art 1kg commercial cocoa roaster. Built using the highest quality stainless steel, combined with other material make HSCR01 become heavy-duty build cocoa roaster.

Thermal and mechanism stability makes the continuous cocoa roasting process much easier with consistent results. HSCR01 is a perfect choice for roasting of high-quality cocoa.

HSCR01 cocoa roaster will help you to get total control of the taste and create your unique product consistently.

15 kg cocoa roaster
cacao roaster 1kg
1kg cocoa roaster
cocoa roaster 1kg
1kg cacao roaster
1kg automated cocoa roaster
1 kg cocoa roaster
1kg cacao roaster dimension



1kg automated cacao roaster ROBUST AND RELIABLE 1KG COCOA ROASTER

HSCR01 are heavy duty cocoa roaster, built with industrial quality, solid construction stainless steel plates. They are built to last. Our machines are also incomparably quiet.

Each machine has an inbuilt variable speed motor, allowing change in speed, thus creating a whisper quiet roaster. The thermal and mechanical stabiliser inside each roaster also allows for continuous production roasting, with ease and consistency



1kg cacao roasterSTARTING FROM DESIGN.

Each of our HSCR cocoa roasters starts with a detailed and thorough design process, so that every detail of the machine provides maximum efficiency and results. Each roaster is designed for maximal durability with low maintenance required. However, not only are our roasters designed for maximal efficiency and results, we also pride ourselves on how our roasters look.

We design our roasters, so that they will shine in your roastery and café. Great effort is given in the designing stage, and we want to invite you into that process. If you have ideas or concepts you wish to try for your own roaster, we will help you to create the custom roaster you desire for your café and roastery.



cocoa roaster burnerHMI WITH AUTOMATED ROASTING MODE

With HARTANZAH logic control panel makes HSCR cocoa roaster series become very accurately automated cocoa roaster. Just select background roasting profile that you want to duplicate and HSCR01 will roast your cocoa bean according selected roasting profile.

There are two options to operate HSCR cocoa roaster, by selecting the roasting mode to full automated or manual mode.



full automated cocoa roaster cooling trayRAPID COOLING SYSTEM

To cooling of the roasted cocoa immidietly after cocoa bean being roasted is a very important factor to maintaining the taste and flavor of the nibs.

HARTANZAH utilizes a powerful blowing motor under the cooling bin that can cool the beans in under five minutes.



cocoa roaster burner MULTI STAGE BURNER

We equip our roasters with HARTANZAH burner technology, this technology makes you easy to control the heat input allowing for your desired preference.

This system combined with airflow controls makes it easier to control conduction, convection and radiation during the roasting process.







HSCR01 Features

High Performace Features
  • Two operating mode (automatic and manual)
  • 10 inch touch screen monitor
  • Soft start and stop function
  • Safe unit shut down
  • Gas leak alarm
  • Flame failure alarm
  • Gas low pressure indicator
  • Adjustable electronic drum speeds controller.
  • Simultaneous roasting and cooling process
  • Stainless steel drum material
  • Automatic roasting by following saved profile
  • Multi stages burner
  • Automated cyclone



Technical Specification

Min batch capacity (Kg) 0,5 Kg
Max batch capacity (Kg) 1 Kg
Roasting time (minutes) Approx 15-40 minutes (Depend on roasting level)
Unit dimension (W-H-L) cm 62 x 87 x 100
Packing dimension (W-H-L) cm 120 x 100 x 100
Unit weight approx 100 kg
Unit weight with wooden packing approx 120 kg
Burner type Multi stages forced Air Burner
Burner Capacity (kcal/hr or (kW) 10 KW
Required gas pressure (mbar) 30-40 mbar (working pressure 20 mbar)
Gas inlet size 0,5 inch
Electrical Requirement (Watt) 500
Supply voltage options 110-120v 60Hz or 220-240V 60Hz Single Phase
Operation options automated and manual
Automation device None
Cyclone outer diameter (inches) 3 inch
Cooling bin outer diameter (inches) 3 inch
Number of motor 1 (Drum)
Number of centrifugal fan 2 (Cooling bin and cyclone)
Differential pressure gauge Yes
Touch screen monitor size 10 inch
Cyclone type Semi automated
Soft start stop Yes
Safe unit shut down Yes
Gas leak alarm Yes
Flame failure alarm Yes
Gas low pressure indicator Yes
Drum material Double wall stainless 6 mm thickness
Catalogue Click here to download
